REPLACEMENT OF CARBON BRUSHES
Replace immediately worn out (shorter than 5 mm), burnt or cracked motor carbon brushes. Always
replace both carbon brushes at a time.
Entrust replacement of carbon brushes only to a qualied person. Only original parts should be
used.
All faults should be repaired by service workshop authorized by the manufacturer.
TECHNICAL PARAMETERS
RATED PARAMETERS
Electric Planer
Parameter Value
Supply voltage 230 V AC
Input current frequency 50 Hz
Rated power 1300 W
Idle rotational speed 16000 rpm
Protection class II
Number of blades 2
Planing width 110 mm
Processing depth for planing 0 – 3,5 mm
Max. processing depth for deep planing 0 - 14 mm
Weight 5 kg
Year of production 2012
NOISE LEVEL AND VIBRATION PARAMETERS
Sound pressure: Lp
A
= 92,8 dB(A) K = 3 dB(A)
Sound power: Lw
A
= 103,8 dB(A) K = 3 dB(A)
Vibration acceleration: a
h
= 5,136 m/s
2
K = 1,5 m/s
2
ENVIRONMENT PROTECTION
Do not dispose of electrically powered products with household wastes, they should be utilized in
proper plants. Obtain information on waste utilization from your seller or local authorities. Used up
electric and electronic equipment contains substances active in natural environment. Unrecycled
equipment constitutes a potential risk for environment and human health.
* Right to introduce changes is reserved.
