DCF/GPS
External input
50
Mounting on DIN rail Connection diagram
CH1 = channel 1
CH2 = channel 2
Installation and mounting
Danger! Risk of electric shock!
Connection and mounting must be realized by a professional electrician!
WARNING
Put the device slightly inclined on top of the rail
Then push it backwards until it engages
LAN module and
timer must be oper-
ated in the same
phase
The distance
between the two
devices must not
be more than 50
meters
