3
Creases: Blow warm air over the area and rub down with a soft cloth.
Wing warp: Hold the panel twisted gently in the opposite direction to the warp, and
apply warm air to remove the creases from the covering.
Caution! do not heat the film more than is absolutely necessary. If the air or the
iron is too hot, the film may melt and holes may be formed.
This aeroplane is highly pre-fabricated and can be built in a very short time.
However, the work which you have to carry out is important and must be done
carefully. The model will only be strong and fly well if you complete your tasks
competently - so please work slowly and accurately.
When self-tapping screws have to be screwed into wood, apply a little white
glue to prevent them shaking loose: just squirt white glue into the hole before
fitting the screw.
Additional accessories required
Power plant and accessories
Engine
Order No.
Propeller
Order No.
Silencer
Order No.
OS MAX 46 AX
7.45 cc
2701
28 x 15 cm
1318.28.15
1809.33
or
1871.72
OS MAX 46 LA
7.64 cc
1888
28 x 15 cm
1318.28.15
1885.33
or
1870.72
Electric motor and accessories
Electric motor
Order No.
Propeller
Order No.
Flight battery
Order No.
Speed controller
Order No.
COMPACT
465 Z
7772
1318.40.25 9733.3 7224
Radio control system
The RC system must feature at least four channels and four servos. The
transmitter should also include a servo reverse facility.
We particularly recommend mx-16 to mc-24 computer systems. The model is
designed for standard-sized servos, e.g. DES585 BB, Order No. 7930.
We recommend the following receiver battery: NH-800 RX, Order No. 7499.4, which
should be maintained carefully before and after each flying session. Please note that
