SNOWBLOWERS, 28" & 34" WALKING
FRAME ASSEMBLY
ITEM NO. PART NO. QTY. DESCRIPTION
1 180075 5 Bolt, Hex; 5/16-18 x 5/8
2 12409 2 Bearing, Flange
3 10579 I Bracket, Gear Box Support
4 120394 13 Washer, Flat; .406 x .812 x .065
5 456004 9 Nut, Lock; 3/2-16 Washer Insert Hex
6 20706 1 Strip, Wear; 28 In.
6412 1 Strip, Wear; 34 In.
7 20707 1 Guard, Snowblower 28 In.
6396 1 Guard, 34 In.
8 180020 2 Bolt, Hex; 1/4-20 x 3/4
9 419455 4 Nut, Lock; 5/16-18 Washer Insert Hex
10 419454 13 Nut, Lock; 1/4-20 Washer Insert Hex
11 413447 5 Nut, Lock; 5/16-18 Type N Hex
12 126485 4 Bolt, 1/2-13 x 1-1/4 RD HD SQ NK
13 180080 4 Bolt, Hex; 5/16-18 x 1-1/8
14 120392 11 Washer, Flat; .281 x .625 x .065
15 180122 4 Bolt, Hex; 3/8-16 x 1
16 120518 4 Bolt, 1/4-20 x 3/4 RD HD SQ NK
17 6477 2 Ring, Bearing
18 435507 8 Nut, Lock; 1/2-13 Washer Insert Hex
19 120396 4 Washer, Flat; .500 x 1.062 x .095
20 24379 2 Skid
21 180177 1 Bolt, Hex; 1/2-13 x 1-1/2
22 20703 1 Weldment, Body; 28 In. Snowblower
20722 1 Weldment, Body; 34 In. Snowblower
23 19479 2 Decal, Caution
24 20994 1 Weldment, Fan Housing
25 6404 1 Chute, Weldment
26 10580 4 Glide
27 445339 4 Nut, Spring Shape 8032 Type A-J
22 20928 2 Spacer, Tube Guard
29 164354 4 Screw, Tapping 8-32 x 3/8 Pan Head Type C
30 6370 1 Guide, Cable Weldment
31 6496 1 Clamp
32 180016 1 Bolt, Hex; 1/4-20 x .50
33 120622 3 Nut, Mach; 8-32 Hex
34 6352 I Baffle, Deflector
35 10496 I Retainer, Baffle
36 21244 I Pin, Self-Locking
37 155886 3 Screw, Mach; 8-32 x 1/2 Flat Hd C-Recess
38 120380 I Washer, Lock; 1/4 SP
39 6464 1 Wing, Deflector
40 6399 1 Chute, Deflector Weldment
41 6381 1 Rope, Wire
42 19740 1 Support
43 180130 2 Bolt, Hex; 3/8-16 x 2
44 20984 1 Bracket, Support
45 180124 3 Bolt, Hex; 3/8-16 x 1-1/4
46 20998 1 Support
47 180175 4 Bolt, Hex; 1/2-13 x 1.25
48 20708 I Support, Weldment
49 180021 3 Bolt, Hex; 1/4-20 x 7/8
50 21020 1 Decal, Snowblower Discharge
51 20985 1 Crank, Support Weldment
52 19297 1 Bushing; .531 x 1.000 x .600
53 126348 2 Bolt, 1/4-20 x 2-1/4 RD HD SQ NK
