SNOWBLOWERS, 38" & 44"
FRAME ASSEMBLY
ITEM NO. PART NO. QTY- DESCRIPTION
1 180075 5 Bolt, Hex; 5/16-18 x 5/8
2 11788 1 Strip, Wear
19791 1 Strip, Wear
3 10579 1 Bracket, Gear Box Support
4 120394 13 Washer, Flat; .406 x .812 x .065
5 456004 9 Nut, Lock; 3/8-16 Washer Insert Hex
6 180020 2 Bolt, Hex; 1/4-20 x 3/4
7 11789 1 Guard
19792 1 Guard
8 12409 2 Bearing, Flange
9 126485 4 Bolt; 1/2-13 x 1-1/4 RD HD SQ NK
10 120518 4 Bolt; 1/4-20 x 3/4 RD HD SQ NK
11 419454 12 Nut, Lock; 1/4-20 Washer Insert Hex
12 419455 4 Nut, Lock; 5/16-18 Washer Insert Hex
13 413447 5 Nut, Lock; 5/16-18 Type N Hex
14 180080 4 Bolt, Hex; 5/16-18 x 1-1/8
15 19479 2 Decal, Caution
16 435507 8 Nut, Lock; 1/2-13 Washer Insert Hex
17 120396 4 Washer, Flat; .500 x 1.062 x .095
18 180122 4 Bolt, Hex; 3/8-16 x 1
19 120392 8 Washer, Flat; .281 x .625 x .065
20 24379 2 Skid
21 6477 2 Ring, Bearing
22 126348 2 Bolt, 1/4-20 x 2-1/4 RD HD SQ NK
23 10580 4 Glide
24 445339 4 Nut, Spring Shape 8032 Type A-J
25 20994 1 Weldment, Fan Housing
26 6404 1 Chute, Weldment
27 164354 4 Screw, Tapping 8-32 x 3/8 Pan Head Type C
28 20928 2 Spacer, Tube Guard
29 6370 1 Guide, Cable Weldment
30 6496 1 Clamp
31 180016 1 Bolt, Hex; 1/4-20 x .50
32 120622 3 Nut, Mach; 8-32 Hex
33 6352 1 Baffle, Deflector
34 10496 1 Retainer, Baffle
35 155886 3 Screw, Mach; 8-32 x 1/2 Flat HD C-Recess
36 120380 1 Washer, Lock; 1/4 SP
37 6464 1 Nut, Deflector Wing
38 6399 1 Chute, Deflector Weldment
39 11809 1 Rod, Push Weldment
40 6381 1 Rope, Wire
41 180175 4 Bolt, Hex; 1/2-13 x 1.25
42 19740 1 Support
43 20984 1 Bracket, Support
44 10405 1 Cotter, Hair Pin
45 131017 1 Washer, Flat; .812 x 1.469 x .134
46 180124 3 Bolt, Hex; 3/8-16 x 1-1/4
47 21020 1 Decal, Snowblower Discharge
48 180130 2 Bolt, Hex; 3/8-16 x 2
49 21008 1 Weldment, Support
50 20998 1 Support
51 20726 1 Weldment, Body; 38 In. Snowblower
20732 1 Weldment, Body; 44 In. Snowblower
52 21005 1 Weldment, Crank Support
53 180021 3 Bolt, Hex; 1/4-20 x 7/8
