SNOWBLOWERS, 28", 34", 38" & 44"
CRANK ASSEMBLY
ITEM NO. PART NO. QTY. DESCRIPTION
1 20984 1 Bracket, Support
2 20999 1 Spring, Compression
3 19340 1 Race, Bearing Thrust; 1.002 x 1.552 x .030
4 20989 1 Shaft
5 456542 2 Pin, Spring; 3/16 x 1-1/2
6 21144 1 Eye, Single
7 20997 1 Assembly, Cable
8 20998 1 Support
9 9630 2 Clamp, Hose SAE; Type F
10 9612 1 Connector
11 10211 1 Grip, Handle
12 120396 1 Washer, Flat; .500 x 1.062 x .095
13 137185 1 Pin, Cotter; .125 x 1.00
14 21005 1 Weldment, Crank Support; 38" & 44"
15 21020 1 Decal, Snowblower Discharge
16 9652 1 Crank, 28" & 34" Snowblower
21022 1 Crank, 38" & 44" Snowblower
17 454563 1 Pin, Spring; 3/16 x 7/8 Cap
18 10210 1 Cap, Stud
19 20985 1 Weldment, Crank Support; 28" & 34"
