THE MANUAL
Before operation of unit, carefully and completely read your
manuals. The contents will provide you with an
understanding of safety instructions and controls during
normal operation and maintenance.
All reference to left, right, front, or rear are given from
operator sitting in operation position and facing the direction
of forward travel.
MODEL AND SERIAL NUMBERS
When ordering replacement parts or
making service inquiries, know the Model
and Serial numbers of your unit and
engine.
Numbers are located on the product
registration form in the unit literature
package. They are printed on a serial
number label, located on the frame of
your unit.
• Record Unit Model and Serial numbers here.
• Record Engine Model and Serial numbers here.
UNAUTHORIZED REPLACEMENT PARTS
Use only Gravely replacement parts. The replacement of
any part on this vehicle with anything other than a Gravely
authorized replacement part may adversely affect
performance, durability, or safety of this unit. Gravely
disclaims liability for any claims or damages, whether
warranty, property damage, personal injury or death arising
out of the use of unauthorized replacement parts.
DISCLAIMER
Gravely reserves the right to discontinue, make changes to,
and add improvements upon its products at any time without
public notice or obligation. The descriptions and
specifications contained in this manual were in effect at
printing. Equipment described within this manual may be
optional. Some illustrations may not be applicable to your
unit.
PRODUCT REGISTRATION
The Gravely dealer must register the product at the time of
purchase. Registering the product will help the company
process warranty claims or contact you with the latest
service information. All claims meeting requirements during
the limited warranty period will be honored, whether or not
the product registration card is returned. Keep a proof of
purchase if you do not register your unit.
Customer Note: If the dealer does not register your
product, please fill out, sign, and return the product
registration card to Gravely.
DELIVERY
Customer Note: Your dealer has been provided complete
setup and preparation instructions which must be completed
before you take delivery of this unit. The dealer is required to
review important information in this manual with you before
or upon delivery of the unit or attachment. If you have
purchased this product without complete assembly and
instruction by your retailer, it is your responsibility to:
1. Read and understand all assembly instructions in this
manual. If you do not understand or have difficulty
following the instructions, contact your nearest Gravely
Dealer for assistance. Make sure all assembly has been
properly completed and safety interlock system works
properly.
TABLE OF CONTENTS
INTRODUCTION
Transfer
model & serial
number label
from product
registration
here.
Figure 1
Serial Number Label
To Next Page
