Horizontal concealed FCU, 3-row-pipes (G series, 220~240VAC, 50Hz, EU)
Model
Item
Unit
FP-34WAS/
GHL-K
FP-51WAS/
GHL-K
FP-68WAS/
GHL-K
FP-85WAS/
GHL-K
FP-102WA
S/GHL-K
FP-136WA
S/GHL-K
FP-170WA
S/GHL-K
FP-204WA
S/GHL-K
Performance
Air flow
High
m
3
/h
370
570
720
870
1020
1360
1600
1900
Mediu
m
260
400
504
610
788
1095
1120
1330
Low
180
280
353
426
525
730
784
931
Cooling
capacity
High
W
2100
3200
4100
4800
5900
7600
8800
10400
Heating
capacity
High
W
2400
3700
4800
5500
6600
8900
10200
12100
Water flow
m
3
/h
0.36
0.55
0.71
0.83
1.02
1.31
1.52
1.79
Water resistance
kPa
20
21
22
30
35
40
33
40
Noise
dB(A)
37
39
40.5
44
48
47
48
50.5
External static
pressure
Pa
0Pa
Coils
Type
Copper tube and lourved fins
Working pressure
≤
1.6MPa
Motor
Type
Class B insulation, capacitor start
Quantity
piece
1
2
Power supply
220-240V
～
50Hz
Protection class
IP20
Input power
W
35
58
66
78
102
161
150
192
Power lines
mm
2
×
piece
0.5
×
3
Anti-electric shock class
I
Fan
Type
Forward multiple-vane low noise centrifugal fan
Quantity
Piece
1
2
3
4
Connection pipe
Inlet
Rc3/4(inner thread)
Outlet
Rc3/4(inner thread)
Condensate
Rc3/4(external thread)
Net weight
kg
14.9
17.4
19.3
21.3
22.7
30.9
34.5
38
Outline dimensions
Width
mm
680
800
900
1000
1080
1380
1520
Depth
mm
500
500
500
500
500
500
500
Height
mm
235
235
235
235
235
235
235
Thermostat
(optional)
Mechanical
Z54352A1
Digital
WK-110PA0
Digital (Deluxe)
WK-010PA-K-K
Notes:
a) The left and right modes can be switched over on site. The correction coefficient for both
cooling and heating is 0.9.
b) Nominal cooling conditions: (27/19
℃
) indoor dry/wet bulb temperature, (7/12
℃
) entering
and leaving water temperature. Nominal heating conditions: 20
℃
indoor dry bulb
temperature, 45
℃
entering water temperature and 40
℃
leaving water temperature.
c) The noise is tested under the semi-anechoic chamber and the actual value will change
under different environments.
