43
Floor Ceiling Type Fan
Coil Unit Service Manual
No.
Discription
FP-68ZD-K FP-85ZD-K FP-102ZD-K
QuantityEM56000130 EM56000120 EM56000140
Name of Part Part Code Part Code Part Code
1 Left Decoration Plate 26112028 26112028 26112032 1
2 Shaft of Louver 10512025 10512025 10512025 2
3 Guide Louver Bracket 24212096 24212096 2690601701 3
4 Guide Louver Fixed Mount 24222016 24222016 24222016 2
5 Shaft of Louver 10512026 10512026 10512026 2
6 Guide Louver 1051953201 1051953201 105124041 1
7 Right Decoration Plate 26112027 26112027 26112033 1
8 Left Mounting Plate of Swing Motor 26152005 26152005 26152407 1
9 Panel Sub-assy 01532001P 01532001P 01532414 1
10 Mounting Box Sub-Assy 201020415 201020415 01326000053 1
11 Display Board 30295502 30295502 30295502 1
12 Button Panel Sub-Assy 201620041 201620041 201620041 1
13 Right Mounting Plate of Swing Motor 26152008 26152008 26152008 1
14 Stepping Motor 15212402 15212402 15212402 2
15 Press Plate of Swing Motor 26112026 26112026 26112026 2
16 Water Tray Component 01279531 01279531 0127241401 1
17 Pipe Hoop 70812001 70812001 70812001 1
18 Drain Pipe Sub-Assy 2690320401 2690320401 2690320401 1
19 Handle 26232001 26232001 26232001 4
20 Foam Sub-assy of Right Side Plate 12312404 12312404 12312407 1
21 Mounting Plate 01332404 01332404 01332404 1
22 Decorative Board 01332404 01332404 01332404 1
23 Mounting Plate Sub-assy 26112033 26112033 26112033 1
24 Electric Box Sub-Assy 01396000130 01396000500 01396000132 1
25 Press Wire Holder 24253001 24253001 24253001 1
26 Press Wire Board 24253002 24253002 24253002 1
27 Terminal Board 42010268 42010268 42010268 1
28 Protective Tube 46010013 46010013 46010013 1
29 Main Board 30225056 30225056 30225056 1
30 Transformer 43110237 43110237 43110237 1
31 Electric Box Cover 01426000030 01426000030 01426000030 1
32 Centifugal Fan 10312401 10312401 10312401 4
33 Capacitor 33010020 33010027 33010027 1
34 Motor 1570730210 1570730211 1501240602 1
35 Axletree 73012403 73012403 73012403 2
36 Front propeller housing 22202031 22202031 22202031 4
37 Rear propeller housing 22202032 22202032 22202032 4
38 Rear Side Plate Sub-assy 01319534 01319534 01302419 1
39 Motor Support Sub-assy 01709532 01709532 01702410 1
40 Filter Sub-assy 11122013 11122013 11122012 1
41 Panel Grille 22412010 22412010 22412011 1
42 Panel Grille Buckle 2 26252003 26252003 26252003 2
43 Remote Control 30510516 30510516 30510516 1
44 Cooling coil assy 01126000068 01126000069 01126000070 1
45 Panel Grille Buckle 1 26252002 26252002 26252002 2
46 Environment Sensor 39000286 39000286 39000286 1
47 Water-leading board assy 02227348P 02227348P 01362401 1
48 Cover Plate Of Evaporator 01072409 01072409 01072417 1
49 Left Decorative Board 26112028 26112028 26112032 1
50 Left Mounting Plate 01332405 01332405 01332405 1
51 Foam Sub-assy of Left Side Plate 12312403 12312403 12312406 1
Above data is subject to change without notice,please refer the SP in global service website.
