46
Floor Ceiling Type Fan
Coil Unit Service Manual
No.
Discription
FP-170WM-D FP-204WM-D
QuantityEM51700150 EM51700160
Name of Part Part Code Part Code
1 Left Decoration Plate 261124152 261124152 1
2 Shaft of Louver 10512025 10512025 3
3 Guide Louver Bracket 2421209601 2421209601 4
4 Guide Louver Fixed Mount 24212018 24212018 3
5 Shaft of Louver 10512026 10512026 2
6 Guide Louver 105124082 105124082 1
7 Right Decoration Plate 261124162 261124162 1
8 Left Mounting Plate of Swing Motor 26152005 26152005 1
9 Panel Sub-assy 01532413 01532413 1
10 Mounting Box Sub-Assy 201020413 201020413 1
11 Display Board 30295502 30295502 1
12 Button Panel Sub-Assy 201620041 201620041 1
13 Right Mounting Plate of Swing Motor 26152006 26152006 1
14 Stepping Motor 1521240211 1521240211 2
15 Press Plate of Swing Motor 26112026 26112026 2
16 Water Tray Component 0127240802 0127240802 1
17 Pipe Hoop 70812001 70812001 1
18 Drain Pipe Sub-Assy 05235433 05235433 1
19 Handle 26232001 26232001 4
20 Foam Sub-assy of Right Side Plate 12312404 12312404 1
21 Mounting Plate 01332404 01332404 1
22 Decorative Board 26112027 26112027 1
23 Mounting Plate Sub-assy 01847502 01847502 1
24 Electric Box Sub-Assy 01396000138 01396000137 1
25 Press Wire Holder 24253001 24253001 1
26 Press Wire Board 24253002 24253002 1
27 Terminal Board 42010268 42010268 1
28 Protective Tube 46010013 46010013 1
29 Main Board 30225056 30225056 1
30 Transformer 43110237 43110237 1
31 Electric Box Cover 01426000030 01426000030 1
32 Centifugal Fan 10319051 10319051 4
33 Capacitor 33010064 33010056 1
34 Motor 1501240501 1501240402 1
35 Axletree 73012403 73012403 2
36 Front propeller housing 22202030 22202030 4
37 Rear propeller housing 22202029 22202029 4
38 Rear Side Plate Sub-assy 1302412 1302412 1
39 Motor Support Sub-assy 01702406 01702406 1
40 Filter Sub-assy 11122013 11122013 1
41 Panel Grille 22412010 22412010 1
42 Panel Grille Buckle 2 26252003 26252003 2
43 Remote Control 30510516 30510516 1
44 Cooling coil assy 01126000071 01126000071 1
45 Panel Grille Buckle 1 26252002 26252002 2
46 Environment Sensor 3900012123 3900012123 1
47 Sensor Insert B 42020063 42020063 1
48 Cover Plate Of Evaporator 01072409 01072409 1
49 Left Decorative Board 26112028 26112028 1
50 Left Mounting Plate 01332405 01332405 1
51 Foam Sub-assy of Left Side Plate 12312403 12312403 1
Above data is subject to change without notice,please refer the SP in global service website.
