Gree FP-34BA2/A-K - Page 50

Wall Mounted Type
Fan Coil Unit Service Manual
48
Spare parts list:
FP-68BA2/A-K (EM55000220); FP-85BA2/A-K (EM55000230); FP-68BA3/A-K (EM55001290);
FP-85BA3/A-K (EM55001360); FP-68BA4/A-K (EM55001300); FP-85BA4/A-K (EM55001370);
FP-68BA5/A-K (EM55000280); FP-85BA5/A-K (EM55000290); FP-68BB3/A-K (EM55001340);
FP-85BB3/A-K (EM55001410); FP-85BA2/A-D(EM55001590); FP-68BA2/D-K (EM55001830);
FP-85BA2/D-K (EM55001840).
No. Name of part
Part code Quantity No. Name of part Part code Quantity
1 Front Panel Assy
20012283
① ② ⑨
1 19 Air Louver 2 10512117 1
20012260
③ ④
20012280
⑤ ⑥
20012286
⑦ ⑧
20012467
2 Filter Sub-Assy 1112208901 2 20 Drainage hose 05230014 1
3 Front Case 20012250 1 21 Pipe Clamp 26112164 1
4 Screw Cover 24252016 1 22 Fan Motor
15012116
① ② ③ ④
⑤ ⑥ ⑦ ⑧
1
1501211601
⑨
5 Display Board
30565039
①②⑤⑥⑨
1 23 Motor Press Plate 26112178
1
30565038
③ ④
30565038
⑦ ⑧
30565037
6
Rubber Plug
(Water Tray)
76712012 1 24 Electric Box 20112108 1
7 Evaporator Assy 24212100 1 25 Main Board 30225045 1
8 Cross Flow Fan 10352019 1 26 Transformer 43110237 1
9 Ring of Bearing 26152022 1 27 Terminal Board 42010268 1
10 Rear Case Assy 12312214 1 28 Electric Box Cover1 20122128 1
11 Wall Mounting Frame 01252218 1 29
Shield cover of
Electric Box
01592092 1
12 Helicoid tongue 26112238 1 30 Electric Box Cover2 20112081 1
13 Air Louver 1 10512116 1 31 Tube Sensor 390000592 1
14 Axile Bush 10542008 1 32
Ambient
Temperature Sensor
390000451 1
15 Left Axile Bush 10512037 1 33 Remote Controller 30510041 1
16 Guide Louver 10512115 1 34 Power Cord 400220112 1
17 crank 10582070 1
35 Jumping Connector
4202300126
① ③ ⑤ ⑦
1
18 Step Motor 15012086 1
4202300120
② ④ ⑥
⑧ ⑨
Note:
①
is part of FP-68BA2/A-K or FP-68BA2/D-K;
②
is part of FP-85BA2/A-K or FP-85BA2/D-K;
③
is part of FP-68BA3/A-K or FP-68BA3/D-K;
④
is part of FP-85BA3/A-K or FP-85BA3/D-K;
⑤
is part of FP-68BA4/A-K or FP-68BA4/D-K;
⑥
is part of FP-85BA4/A-K or FP-85BA4/D-K;
⑦
is part of FP-68BA5/A-K or FP-68BA5/D-K;
⑧
is part of FP-85BA5/A-K or FP-85BA5/D-K;
⑨
is part of FP-85BA2/A-D; is part of FP-68BB3/A-K; is part of FP-85BB3/A-K.
