Service Manual
Installation and Maintenance
41
No.
Description
Part Code
QtyGAC09AA-A3RNA2C GAC12AA-A3RNA2C
Product Code CC060036400 CC060036500
1 Filter 1112103002 1112103002 1
2 Guide Blade Lever 1058290403 1058290403 2
3 Guide Louver 2 1051290901 1051290901 4
4 Guide Louver 1 1051290801 1051290801 1
5 Ratchet Wheel 24232901 24232901 1
6 Supporting Strip 2421290601 2421290601 3
7 Front Panel 2000141601 2000141601 1
8 Front Panel Assy 00800600001 00800600001 1
9 Membrane 63061341 63061341 1
10 Remote Control Cover 2012103301 2012103301 1
11 Display Board 30562084 30562084 1
12 Power Cord(LCDI) 4002036350 4002036350 1
13 Electric Box Assy 10000201718 10000201719 1
14 Capacitor CBB61 33010069 33010069 1
15 Capacitor CBB61S 3301074714 3301074714 1
16 Capacitor CBB65 3300008113 3300008105 1
17 Terminal Board 42011103 42011103 1
18 Main Board 30132189 30132189 1
19 Temperature Sensor 390000598 390000598 1
20 Ambient Temperature Sensor 3900019813 3900019813 1
21 Transformer 4311025601 4311025601 1
22 Evaporator Assy 01100100159 01100100155 1
23 Front Clapboard Assy 01231098 01231098 1
24 Rear grill 01451001 01451001 1
25 Air Louver 10512907 10512907 5
26 Swing Louver Clamp 24211045 24211045 1
27 Water Tray 12412901 12311027 1
28 Centrifugal fan 10312903 10312903 1
29 Propeller housing Assy 22201017 22201017 1
30 Propeller Housing 22201020 22201020 1
31 Bafe Plate 26112905 26112905 1
32 Fan Motor 150110347 150110347 1
33 Connection Board 01382902P 01382902P 1
34 Motor Support 01702901P 01702901P 1
35 Fan Motor 150110336 150110336 1
36 Diversion Circle 10371005 10371005 1
37 Axial Flow Fan 10331012 10331012 1
38 Top Cover 20121106 20121106 1
39 Condenser Assy 01100200247 01100200248 1
40 Drainage Valve 07101001 07101001 1
41 Chassis Sub-assy 01201065P 01201236P 1
42 Compressor Overload Protector 00181159 00181016 1
43 Compressor and Fittings 00101352 00101384 1
44 Compressor Gasket 76710250 02111018 3
45 Capillary Sub-assy 03000600238 03000600217 1
46 Discharge Tube 03500800364 03500800365 1
47 Inhalation Tube 03500600329 03500600330 1
48 Remote Controller 30510092 30510092 1
Above data is subject to change without notice.
