5HPRYDO3URFHGXUH

Steps Procedure

4.Remove swing assy

5.Remove water tray assy

6.Remove electric box assy

screw

swing assy

water tray assy

electric box assy

Remove 2 screws fixing swingassy, pull

out the connection wires with electric box,

and then pull the swing assy outwards

to remove it.

Remove 2 screws fixing water tray, and

then pull the water tray outwards to

remove it.

Remove one screw fixing electric box

assy,pull out all connection wire, and

then pull the electric box assy outwards

to remove it.
