Gree GMV-ND280PH/A-T - Page 189

MULTI VRF-Ⅱ INDOOR UNIT SERVICE MANUAL EUROPEAN/LATIN AMETICA (R410A)
185
Above data is subject to change without notice,pls reference the SP in global service website.
13
Front Connection Board
'01349414P
1
14
Air Louver
'10619404
16
15
Rotating Shaft
'26909430
4
16
Guide Louver Supporter Sub-
assy
'0180941601
1
17
Fixed Mount
'26909426R
1
18
Display Board
'30294000009
1
19
Rear Side Plate Assy
'01319400008
1
20
Evaporator Assy
'01024100126(28)
'01024100096(36
、
50)
1
21
Rotating Shaft
'26909413
1
22
Connecting Rod
'26909411
1
23
Rotating Shaft
'26909412
1
24
Stepping Motor
'1521240206
1
25
Installation Supporting Frame
'01809401
1
26
Left Side Plate Sub-Assy
'01319428
1
27
Electric Box Assy
'01394100343
1
28
Main Board
'30226000029
1
29
Electric Box Cover
'01429420
1
30
Left Cover Plate
'26909443
1
31
Terminal Board
'42011106
1
32
Terminal Board
'4201800002601
1
33
Mid-clapboard sub-assy
'01249400004
1
34
Support Of Motor Bearing
'01792408
2
35
O-Gasket of Bearing
'76512404
2
36
Rotary Axis Sub-Assy
'73018000037
2
37
Centrifugal Fan
'10425200
4
38
Joint Slack
'73018731(36
、
50)
2
39
Supporter
'01809400024
1
40
Fan Motor
'15704100001
1
41
Supporter
'01809400023
1
42
Rear Connection board
'01349422
1
43
Front Volute Casing
'26905205
4
44
Rear Volute Casing
'26905206
4
45
Remote Controller
'30510589
1
46
Electric expand valve fitting
'4304413203
1
47
Water Tray Assy
'01289404
1
48
Top Cover Board Sub-assy
'01269409
1
49
Front Grill sub-assy
'01579403
2
50
Drainage Pipe Sub-assy
'05235434
1
