Gree GMVVQ224WM/C-X - Page 11

GMV Heat Recovery DC Inverter VRF
7
Model
GMV-
VQ224WM/
C-X
GMV-
VQ280WM/
C-X
GMV-
VQ335WM/
C-X
GMV-
VQ400WM/
C-X
GMV-
VQ450WM/
C-X
GMV-
VQ504WM/
C-X
GMV-
VQ560WM/
C-X
GMV-
VQ615WM/
C-X
GMV-
VQ2015W
M/C-X
◆ ◆◆ ◆
GMV-
VQ2070W
M/C-X
◆ ◆ ◆◆
GMV-
VQ2125W
M/C-X
◆ ◆◆◆
GMV-
VQ2180W
M/C-X
◆ ◆◆◆
GMV-
VQ2245W
M/C-X
◆ ◆◆◆
GMV-
VQ2295W
M/C-X
◆ ◆◆◆
GMV-
VQ2349W
M/C-X
◆ ◆◆◆
GMV-
VQ2405W
M/C-X
◆ ◆◆◆
GMV-
VQ2460W
M/C-X
◆◆◆◆
NOTE:
◆
means a basic module.
2.2.2 Combinations of Indoor and Outdoor Units
(1) The following table indicates the number of IDU for ODU
：
ODU model
Max number of connectable
IDU (unit)
ODU model
Max number of connectable
IDU (unit)
GMV-VQ224WM/C-X
13
GMV-VQ1400WM/C-X
66
GMV-VQ280WM/C-X
16
GMV-VQ1455WM/C-X
69
GMV-VQ335WM/C-X
19
GMV-VQ1510WM/C-X
71
GMV-VQ400WM/C-X
23
GMV-VQ1565WM/C-X
74
GMV-VQ450WM/C-X
26
GMV-VQ1630WM/C-X
77
GMV-VQ504WM/C-X
29
GMV-VQ1680WM/C-X
80
GMV-VQ560WM/C-X
33
GMV-VQ1734WM/C-X
80
GMV-VQ615WM/C-X
36
GMV-VQ1790WM/C-X
80
GMV-VQ680WM/C-X
39
GMV-VQ1845WM/C-X
80
GMV-VQ730WM/C-X
43
GMV-VQ1905WM/C-X
80
GMV-VQ784WM/C-X
46
GMV-VQ1959WM/C-X
80
GMV-VQ840WM/C-X
50
GMV-VQ2015WM/C-X
80
GMV-VQ895WM/C-X
53
GMV-VQ2070WM/C-X
80
GMV-VQ950WM/C-X
56
GMV-VQ2125WM/C-X
80
GMV-VQ1015WM/C-X
59
GMV-VQ2180WM/C-X
80
GMV-VQ1065WM/C-X
63
GMV-VQ2245WM/C-X
80
GMV-VQ1119WM/C-X
64
GMV-VQ2295WM/C-X
80
GMV-VQ1175WM/C-X
64
GMV-VQ2349WM/C-X
80
GMV-VQ1230WM/C-X
64
GMV-VQ2405WM/C-X
80
GMV-VQ1290WM/C-X
64
GMV-VQ2460WM/C-X
80
GMV-VQ1345WM/C-X
64
— —
(2) The total capacity of indoor units should be within 50%~135% of that of outdoor units.
