42
Maintenance
Service Manual
No.
Description
PartCode
QtyGPC12AF-K3NNA7A GPC12AF-K3NNA7D
Product Code CK01001212 CK010021500 CK010021501
1 Decorative Board sub-assy 20196011 20196011 20196011 1
2 Decorative Board 20196006S 20196006S 20196006S 1
3 Decorative Block 20196013 20196013 20196013 1
4 Decorative Strip 20196012 20196012 20196012 1
5 Front Panel Sub-Assy 20006061 20006177 20006177 1
6 Front Panel 20006059 20006059 20006059 1
7 Display Board 30567028 30567028 30567028 1
8 Button 45036021 45036021 45036021 1
9 Fan Motor 1501603903 1501603902 1501603902 1
10 Motor holder (upper) 26156043 26156043 26156043 1
11 Electric Box Assy 01406540 10000200174 10000200174 1
12 Main Board 30137047 30137047 30137047 1
13 Ambient Temperature Sensor 390000591 390000591 390000591 1
14 Tube Sensor 390000594 390000451 390000451 1
15 Capacitor CBB65 33010743 3300008102 3300008102 1
16 Capacitor CBB61 33010025 3301074702 3301074702 1
17 Capacitor CBB61 33010027 3301074704 3301074704 1
18 Transformer 43110043 43110043 43110043 1
19 Electric Box Cover 01416010 01416010 01416010 1
20 Propeller Housing 12316036 12316036 12316036 1
21 Gear Sub-Assy 10546005 10546005 10546005 1
22 Centrifugal fan 10316058 10316058 10316058 1
23 Guide Louver 1 10516051 10516051 10516051 1
24 Guide Louver 2 10516052 10516052 10516052 1
25 Diversion Circle (upper) 10376035 10376035 10376035 1
26 Step Motor 1521210301 1521210301 1521210301 1
27 Left Axile Bush 10512037 10512037 10512037 1
28 Crank 10582070 10582070 10582070 1
29 Mid-Clapboard 20056095 20056095 20056095 1
30 Water Tray 12416008 12416008 12416008 1
31 Evaporator Assy 01006050 01006510 01100100021 1
32 Filter Sub-Assy 11126011 11126011 11126011 1
33 Rear Plate Sub-Assy 20056105 20056105 20056105 1
34 backboard 1 20056096 20056096 20056096 1
35 Remote control box 20116012 20116012 20116012 1
36 Cover of Remote control box 20126072 20126072 20126072 1
37 Cable Cross Plate 26116060 26116060 26116060 1
38 Latch 70810302 70810302 70810302 1
39 Condenser Assy 0110610301 0110610301 01106103 1
40 Motor holder b (lower) 26156046 26156046 26156046 1
41 Fan Motor 1501603902 1501603903 1501603902 1
42 Centrifugal fan 10316058 10316058 10316058 1
43 Diversion Circle (lower) 10376034 10376034 10376034 1
44 Discharge Tube 03616079 03616079 03616079 1
45 InhalationTube 03626095 03626095 03626095 1
46 Compressor and ttings 00103781G 00103781G 00103781G 1
47 Compressor Gasket 76710253 76710247 76710247 3
To Next Page
