Gree GUHD18ND3FO - Product Data; Product Data of Indoor Unit

U-Match Series DC Inverter Service Manual
5
3 PRODUCT DATA
3.1 Product Data of Indoor Unit
3.1.1 Duct Type
Model
Indoor unit
GFH18D3FI
GFH24D3FI
GFH30D3FI
Product Code
CF060N0512
CF060N0513
CF060N0522
CF060N0523
CF060N0580
CF060N0590
Outdoor unit
GUHD18ND3FO
GUHD24ND3FO
GUHD30ND3FO
Product Code
CF090W0751
CF090W0761
CF090W0830
Capacity
Cooling Capacity
Btu/h
17100(5400~19800)
23800(7400~29000)
28200(8200~29600)
Heating Capacity
Btu/h
18800(4700~23200)
27200(8200~32400)
31200(8200~33600)
Power Input
Cooling
kW
1.55(0.55~1.75)
2.23(0.85~2.50)
3.30(0.85~3.70)
Heating
kW
1.65(0.50~1.90)
2.36(0.80~2.75)
3.10(0.80~3.50)
SEER / HSPF
(Btu/h)/W
16.00/9.50
16.00/9.00
16.00/9.00
Indoor Unit
GFH18D3FI
GFH24D3FI
GFH30D3FI
Power Supply
V/Ph/Hz
208/230V~60Hz
208/230V~60Hz
208/230V~60Hz
Heat Exchange
-
Cross Fin Coil
Cross Fin Coil
Cross Fin Coil
Fan
Drive
-
Direct
Direct
Direct
Motor Output
kW
0.06×1
0.15×1
0.15×1
Air Flow
m
3
/h(CFM)
1000(585)
1400(820)
1400(820)
Rated Ext. Static
Pressure
Pa(InWg)
25(0.1)
25(0.1)
37(0.15)
Ext. Static Pressure
Range
Pa(InWg)
0~30(0~0.12)
0~75(0~0.3)
0~75(0~0.3)
Sound Pressure Level(SS/H/M/L)
dB(A)
40/39/36/28
47/46/44/40
47/46/44/40
Air Filter
-
PP
PPKZ
PPKZ
Drain Piping
mm(inch)
Φ30×1.5
(φ1.18×0.06)
Φ20×1.2
(φ0.79×0.05)
Φ20×1.2
(φ0.79×0.05)
Outline Dimensions (W×H×D)
mm
(inch)
1037×266×721
(40.8×10.5×28.4)
1279×268×558
(50.4×10.6×22.0)
1279×268×558
(50.4×10.6×22.0)
Net Weight
kg(lb)
33.0(72.8)
34.0(75.0)
35.0(77.2)
Outdoor Unit
GUHD18ND3FO
GUHD24ND3FO
GUHD30ND3FO
Power Supply
V/Ph/Hz
208/230V~60Hz
208/230V~60Hz
208/230V~60Hz
Heat Exchange
-
Cross Fin Coil
Cross Fin Coil
Cross Fin Coil
Compressor
Type
-
Rotary
Rotary
Rotary
Power Input
W
1440
2550
2550
Refrigerant
Control
-
Electronic Expansion
Valve
Electronic Expansion
Valve
Electronic Expansion
Valve
Charge
kg(oz)
1.4(49.4)
2.2(77.6)
2.4(84.7)
Outline Dimensions (W×H×D)
mm(inch)
955×700×396
(37.6×27.6×15.6)
980×790×427
(38.6×31.1×16.8)
980×790×427
(38.6×31.1×16.8)
Net Weight
kg(lb)
48.0(105.8)
69.0(152.1)
72.0(158.8)
Piping
Connections
Liquid
Inch
Φ1/4
Φ3/8
Φ3/8
Gas
Inch
Φ1/2
Φ5/8
Φ5/8
Max. Length
m(ft)
20(65.6)
30(98.4)
30(98.4)
Max. Height
m(ft)
15(49.2)
15(49.2)
15(49.2)
