Gree GWC09KF-D3DNA5A User Manual

85
Loosen the 1 screws
and remove the
discharge grille.
2
Loosen the 5 screws of
the front panel.
3
1
Remove the fan motor
The screw has reverse
winding.
Remove the propeller
fan.
Front panel.
Propeller fan.
Lift the front panel and
remove it while pushing the
right side panel inwards.
Step Procedure Points
Removal Procedure
Remove the 5 screws from
the edge between right-side
board and condenser and from
valve. Lift to remove the right-side
board subassembly.
Remove the screws of the fan by
wren
a
nd
then remove the
fan
.
ch
axial flow

Gree GWC09KF-D3DNA5A Specifications

General

Brand	Gree
Model	GWC09KF-D3DNA5A
Category	Air Conditioner
Language	English
