Gree GWC09NA-D3NNA3A/I


5HPRYDO3URFHGXUH
motor clamp
O-gasket sub-assy
of bearing
ring of
bearing
2
3
4
5
Remove the screw of the motor clamp
and then remove the clamp.
Remove the cross flow blade and motor.
cross flow blade
motor
Remove the rubber cushion of the bearing.
Remove the screws at the joint of the cross flow
blade and the motor. Take down the motor.
cross flow blade
motor
