Technical Information
Service Manual
Model GWH09QB-A3DNB8K GWC12QC-D3DNC8H
Product Code CB438008000 CB456003101
Power Supply
Rated Voltage V~ 115 208/230
Rated Frequency Hz 60 60
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity(Min~Max) Btu/h 9000 12000(3753~12500)
Heating Capacity(Min~Max) Btu/h 9500 /
Cooling Power Input(Min~Max) W 900 1300(410~1350)
Heating Power Input(Min~Max) W 870 /
Cooling Power Current A 10.87 5.8
Heating Power Current A 10.36 /
Rated Input W 1270 1350
Rated Current A 12.66 6.0
Air Flow Volume(SH/H/M/L) CFM 318/288/241/171 400/318/241/194
Dehumidifying Volume Pint/h 1.69 2.96
EER (Btu/h)/W 10.00 9.23
COP (Btu/h)/W 10.92 /
SEER 18.00 16.00
HSPF 9.00 /
Application Area yd
2
14.35-21.53 19.14-28.70
Indoor Unit
Model of indoor unit GWH09QB-A3DNB8K/I GWC12QC-D3DNC8H/I
Indoor Unit Product Code CB438N08000 CB456N03101
Fan Type Cross-ow Cross-ow
Diameter Length(DXL) inch Φ3 7/8X24 15/16 Φ3 7/8X25
Fan Motor Cooling Speed(SH/H/M/L) r/min 1350/1200/1050/750 1350/1200/1000/800/-
Fan Motor Heating Speed(SH/H/M/L) r/min 1350/1200/1050/850 /
Output of Fan Motor W 20 20
Fan Motor RLA A 0.24 0.31
Fan Motor Capacitor μF 4 1.5
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter inch Φ3/16 Φ3/16
Row-n Gap inch 2-1/18 2-1/16
Coil Length (LXDXW) inch 23X7/8X10 1/2 25X7/8X12 1/16
Swing Motor Model MP24AA MP24BA
Output of Swing Motor W 1.5 1.5
Fuse A 3.15 3.15
Sound Pressure Level(SH/H/M/L) dB (A) 43/38/34/28 45/39/35/29/-
Sound Power Level(SH/H/M/L) dB (A) 53/48/44/28 55/49/45/39/-
Dimension (WXHXD) inch 31 1/8X10 13/16X7 7/8 33 1/4X11 3/8X8 1/4
Dimension of Carton Box (LXWXH) inch 34X10 9/16X13 7/8 36 1/8X11X14 5/16
Dimension of Package (LXWXH) inch 34 1/8X10 11/16X14 7/16 36 1/4X11 1/16X15
Net Weight Ib 20.9 22.05
Gross Weight Ib 25.4 26.46
