12
Technical Information
Service Manual
Outdoor Unit
Model of Outdoor Unit GWH09QB-A3DNA5K/O GWC12QC-D3DNA6H/O
Outdoor Unit Product Code CB425W08200 CB427W05800
Compressor Manufacturer/Trademark
ZHUHAI LANDA COMPRESSOR
CO.,LTD
ZHUHAI LANDA COMPRESSOR
CO,LTD.
Compressor Model QXA-A091zE190 QXA-B102zE190
Compressor Oil FVC68D or RB 68EP RB68EP
Compressor Type Rotary Rotary
Compressor Locked Rotor Amp (L.R.A) A 40 /
Compressor RLA A 12.62 6.6
Compressor Power Input W 980 1020
Overload Protector
1NT11L-6233 or KSD115ºC or
HPC115/95U1
/
Throttling Method Electric Expansion Valve Capillary
Operation temp ºF 61~86 60.8~86
Ambient temp (cooling) ºF 0~115 0~115
Ambient temp (heating) ºF -4~75 /
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter inch Φ1/4 Φ5/16
Rows-n Gap inch 1-1/18 2-1/16
Coil Length (LXDXW) inch 29 3/4X3/4X20 28X1 1/2X20
Fan Motor Speed rpm 850 820
Output of Fan Motor W 30 30
Fan Motor RLA A 0.24 0.37
Fan Motor Capacitor μF / 2.5
Air Flow Volume of Outdoor Unit CFM 1059 942
Fan Type Axial-ow Axial-ow
Fan Diameter inch Φ15 3/4 Φ15 3/4
Defrosting Method / /
Climate Type T1 T1
Isolation I I
Moisture Protection IPX4 IPX4
Permissible Excessive Operating
Pressure for the Discharge Side
PSIG 550 620
Permissible Excessive Operating
Pressure for the Suction Side
PSIG 240 360
Sound Pressure Level (H/M/L) dB (A) 52/-/- 52/-/-
Sound Power Level (H/M/L) dB (A) 62/-/- 62/-/-
Dimension (WXHXD) inch 33 3/8X21 1/4X12 5/8 30 9/16X21 1/4X12 5/8
Dimension of Carton Box (LXWXH) inch 34 9/16X14 3/16X22 13/16 33 3/8X14X22 13/16
Dimension of Package (LXWXH) inch 34 11/16X14 5/16X23 7/16 33 3/8X14 1/4X23 7/16
Net Weight Ib 62.8 67.24
Gross Weight Ib 68.4 72.75
Refrigerant R410A R410A
Refrigerant Charge oz 24.7 31.8
Connection
Pipe
Length ft 24.6 24.6
Gas Additional Charge oz/ft 0.2 0.2
Outer Diameter Liquid Pipe inch Φ1/4 Φ1/4
Outer Diameter Gas Pipe inch Φ3/8 Φ3/8
Max Distance Height ft 32.8 32.8
Max Distance Length ft 65.6 49.2
Note:The connection pipe applies metric diameter.
The above data is subject to change without notice. Please refer to the nameplate of the unit.
