GWH12QC-A3DNC8E/I GWH12QC-A3DNB2K/I GWC12QC-A3DNB2K/I
Product Code CB456N02400 CB432N09100 CB432N08900
1 Front Panel 20000300154T 20000300018 20000300018 1
2 Front Case 00000200045 00000200045 00000200045 1
3 Axile Bush 10542036 10542036 10542036 1
4 Helicoid Tongue 26112436 26112436 26112436 1
5 Left Axile Bush 10512037 10512037 10512037 1
6 Display Board 30565281 30565260 30565260 1
7 Rear Case assy 00000100093 00000100093 00000100093 1
8 Rubber Plug (Water Tray) 76712012 76712012 76712012 1
9 O-Gasket sub-assy of Bearing 7651205102 7651205102 7651205102 1
10 Ring of Bearing 26152022 26152022 26152022 1
11 Cold Plasma Generator / / / /
12 Evaporator Assy 0100297601 0100297601 0100297601 1
13 Wall Mounting Frame 01252484 01252484 01252484 1
14 Cross Flow Fan 10352056 10352056 10352056 1
15 Fan Motor 1501214605 1501214605 1501214605 1
16
Connecting pipe clamp
2611216401 2611216401
2611216401
1
17 Drainage Hose 05230014 05230014 05230014 1
18 Stepping Motor 1521210710 1521210710 1521210710 1
19 Crank 73012005 73012005 73012005 1
20 Electric Box Assy 100002002628 100002001623 100002001624 1
21 Terminal Board 42011233 42011233 42011233 1
22 Jumper 4202021917 4202021917 4202021917 1
23 Main Board 300002000307 300002000307 300002000308 1
24 Electric Box Cover Sub-Assy 0140206501 0140206501 0140206501 1
25 Shield Cover of Electric Box Cover 01592150 01592150 01592150 1
26 Electric Box Cover 2011220701 2011220701 2011220701 1
27 Power Cord / / / /
28 Connecting Cable / / / /
29 Evaporator Support 24212179 24212179 24212179 1
30 Remote Controller 30510475 30510475 30510475 1
31 Detecting plate(WIFI) 000409000004 000409000004 000409000004 1
