78
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
No.
Description
Part Code
Qty
GWH09QB-A3DNB8K/I GWH09QB-A3DNC2E/I
Product Code CB438N08000 CB439N06001
1 Front Panel 20000300073T 20000300068S 1
2 Front Case 2002248001 2002248001 1
3 Axile Bush 10542036 10542036 1
4 Helicoid Tongue 26112508 26112508 1
5 Left Axile Bush 10512037 10512037 1
6 Display Board 30565260 30565281 1
7 Rear Case assy 00000100066 00000100066 1
8 Rubber Plug (Water Tray) 76712012 76712012 1
9 O-Gasket sub-assy of Bearing 7651205102 7651205102 1
10 Ring of Bearing 26152022 26152022 1
11 Cold Plasma Generator / / /
12 Evaporator Assy 0100200004407 0100200004407 1
13 Wall Mounting Frame 01252043 01252043 1
14 Cross Flow Fan 10352059 10352059 1
15 Fan Motor 1501208902 1501208902 1
16 Connecting pipe clamp 2611216401 2611216401 1
17 Drainage Hose 0523001408 0523001408 1
18 Stepping Motor 1521212901 1521212901 1
19 Crank 73012005 73012005 1
20 Electric Box Assy 100002001620 100002003669 1
21 Terminal Board 42011233 42011233 1
22 Jumper 4202021911 4202021911 1
23 Main Board 300002000307 300002000307 1
24 Electric Box Cover Sub-Assy 0140206501 0140206501 1
25 Shield Cover of Electric Box Cover 01592150 01592150 1
26 Electric Box Cover 2011220701 2011220701 1
27 Power Cord / / /
28 Connecting Cable / / /
29 Evaporator Support 24212180 24212180 1
30 Remote Controller 30510475 30510475 1
31 Detecting plate(WIFI) 30070079 000409000003 1
To Next Page
