Gree GWC24QE-D3DNB2R/O

175
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
No.
Description
Part Code
Qty
GWC24QE-D3DNB2R/O
Product Code CB432W21600
1 Axial Flow Fan 10333023 1
2 Fan Motor 1501506406 1
3 Electric Box Assy 100002067145 1
4 Electric Box 20113027 1
5 Radiator 49013060 1
6 Main Board 300027060878 1
7 Electric Box Cover 20123028 1
8 Terminal Board 42200006001401 1
9 Handle 26233014 1
10 Left Side Plate 01303025 1
11 Coping 01253105 1
12 Motor Support Sub-Assy 01701200009 1
13 Clapboard Sub-Assy 017021000063 1
14 Condenser Assy 011002061015 1
15 Discharge Tube-Assy 035008061748 1
16 Rear Grill 016001000023 1
17 Electronic Expansion Valve Rope 4300034419 1
18 Right Side Plate-Assy 00008100002101 1
19 Handle 26233014 1
20 Valve Cover 22243015 1
21 Cut off Valve Sub-Assy 5/8 030057060124 1
22 Electronic Expansion Valve assy 030174060086 1
23 Valve Support Sub-Assy 017104060025P 1
24 Compressor and Fittings 009001060387 1
25 Chassis 01213080 1
26 Drainage Joint / /
27 Suction Tube-Assy 030010060798 1
28 Cabinet 0143307201P 1
29 Front Grill 01473008 1
