Gree GWC30LB-D3DNA3G

26
Installation and Maintenance
Service Manual
8. Installation
8.1 Installation Dimension Diagram
Space to the ceiling
Space to the wall
At least 5 7/8 inch
At least 98 7/16 inch
At least 5 7/8 inch
At least 5 7/8 inch
Space to the wall
Space to the obstruction
roolf eht ot ecapS
Space to the obstruction
Drainage pipe
Space to the wall
Space to the obstruction
Space to the obstructio
Space to the obstruction
At least 19 11/16 inch
At least 11
7/8
inch
At least 19 11/16 inch
At least 11 7/8 inch
At least 78 3/4 inch
At least 118 inch
