Technical Information
Service Manual
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Model
GWH(12)KF-K3DNA6E/I
GWH(12)KF-K3DNB4E/I
GWH(12)KF-K3DNB1E/I
GWH(12)KF-K3DNA5E/I
GWH(12)KF-K3DNA6E/I
GWH(12)KF-K3DNB2E/I
GWH(18)KG-K3DNA6E/I
GWH(18)KG-K3DNB2E/I
GWH(18)KG-K3DNB1E/I
GWH(18)KG-K3DNA5E/I
Product Code
CB146N26401
CB146N33400
CB146N30500
CB146N33001
CB146N26402
CB409N00900
(CB146N32500/CB146N26501)
CB409N01900
CB146N35400
CB146N32901
Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Cooling Capacity KW 3.5 5.3
Heating Capacity KW 3.8 5.8
Air Flow Volume (SH/H/M/L) m
3
/h 680/560/410/300 800/680/560/460
Dehumidifying Volume L/h 1.4 1.8
Fan Type Cross-ow Cross-ow
Fan Diameter-height mm Φ92X594 Φ98X710
Fan Motor Speed (SH/H/M/L) Cool rpm 1350/1150/950/750 1350/1100/950/800
Fan Motor Speed (SH/H/M/L) Heat rpm 1350/1190/1020/850 1400/1200/1050/900
Fan Motor Power Output W 10 20
Fan motor running current A 0.16 0.31
Fan Motor Capacitor μF 1.2 1.5
Evaporator Material Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm 7 7
Evaporator Number of Rows 2 2
Evaporator Fin Pitch mm 1.4 1.4
Evaporator Length(L) X Height(H) X Width(W) mm 610X25.4X294 657X25.4X304.8
Motor Model FN10V-PG FN20V-PG
Overload Protector 3.15 3.15
Motor Full Load Amp(FLA) A 0.16 0.31
Sound Pressure Level (SH/H/M/L) dB (A) 42/39/31/25 45/40/37/32
Sound Power Level (SH/H/M/L) dB (A) 52/49/41/35 55/50/47/42
Outline Dimension (WXHXD) mm 770X283X201 865X305X215
Package Carton Dimension (LXWXH) mm 844X342X261 945X380X295
Package Dimension (LXWXH) mm 847X345X276 948X383X310
Net Weight kg 9 12
Gross Weight kg 11 15
Liquid Pipe mm Φ6 Φ6
Gas Pipe(to Indoor Unit) mm Φ9.52 Φ12
