60
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
Qty
GWH07AGA-K3NNA1B/O GWH09AGB-K3NNA1B/O
Product Code CA385W00300 CA385W00200
1
Front Grill 22263002 22263002 1
2
Front Panel 01533255P 01533255P 1
3
Fan Motor 1501315604 1501315604 1
4
Chassis Sub-assy 017000000107P 0280312302P 1
5
Drainage Connecter 06123401 06123401 1
6
Compressor and Fittings 009001060526 009001000101 1
7
Magnet Coil 4300040047 4300040047 1
8
4-Way Valve 430004022 430004022 1
9
4-Way Valve Assy 030152060484 030152000150 1
10
Capillary Sub-assy 030006060684 030006060694 1
11
Right Side Plate Sub-Assy 01303243 01303243 1
12
Valve 07100005 07100005 1
13
Valve 07133727 07133727 1
14
Big Handle 2623304202 2623304202 1
15
Valve Support 01713041 01713041 1
16
Terminal Board 420001000003 420001000003 1
17
Capacitor CBB61S 3301074701 3301074701 1
18
Capacitor CBB65 3300008102 33000081 1
19
Electric Box Assy 100002064976 100002067112 1
20
Rear Grill 01473041 01473041 1
21
Condenser Assy 011002060951 011002060965 1
22
Top Cover Plate 01253045P 01253045P 1
23
Motor Support Sub-Assy 01703204 01703204 1
24 Clapboard Sub-Assy 01233207 01233207 1
25 Axial Flow Fan 10333002 10333002 1
26 Small Handle 26233100 26233100 1
To Next Page
