Gree GWH12QB-K6DNB4A

54
Technical Information
Service Manual
Outdoor Unit
1
2
3
4
5
6
7
8
9
No. Name
1 Earthing wire
2
Neutral wire, live wire and
communication cable
3 4-way valve
4 Electric heating belt of chasssis
5 Outdoor fan
6 Electronic expansion valve
7 Overload
8 Temperature sensor
9 Three-phase terminal of compressor
07K/09K/12K
GWH18ALD-K6DNA1A/O
