Gree GWH24AFE-K6DNA2I/O

122
Installation and Maintenance
Service Manual
NO. Description
1
Front Panel Assy
2 Display Board
3
Front Case Assy
4
Axile Bush
5 Helicoid Tongue
6 Left Axile Bush
7 Rear Case assy
8
Rubber Plug (Water Tray)
9 O-Gasket sub-assy of Bearing
10 Ring of Bearing
11 Cold Plasma Generator
12 Evaporator Assy
13
Wall Mounting Frame
14 Cross Flow Fan
15
Fan Motor
16 Connecting pipe clamp
17 Drainage Hose
18 Stepping Motor
19 Crank
20 Electric Box Assy
21 Terminal Board
22
Jumper
23
Main Board
24 Electric Box Cover Sub-Assy
25 Shield Cover of Electric Box Cover
26 Electric Box Cover
27 Connecting Cable
28 Remote Controller
29 Evaporator Support
Some models may not contain some parts, please refer to the actual product.
