Use suitable instruments for the refrigerant R410A.
Do not use mineral oils to clean the unit.
The installation must be done by trained and licensed service personnel adhereing to the instructions
provideded in this manual.
Contact a licensed HVAC contractor for installation to avoid any issues that will void the warranty.
Any disconnecting and relocation of a unit must be done by a qualified licensed HVAC technician.
Ensure that the minimum spacing requirements (below) are adhered to.
Do not use any other refrigerant than R410A.
MAINTENANCE INSTALLER
INSTALLATION DIMENSION DIAGRAM INSTALLER
11
MULTIU24HP230V1DO MULTIU18HP230V1DO
MULTIU36HP230V1DO MULTIU42HP230V1DO
(Air inlet side)
(Air outlet side)
(Air inlet side)
79 in min
12 in min
(Air inlet side)
20 in min
12 in min
20 in
min
12 in min
12 in min
20 in min
20 in
min
79 in min
79 in min
(Air outlet side)
(Air outlet side)
12 in min
12 in min
20 in min
20 in min
