GREE U-Match 6 SERIES UNIT SERVICE MANUAL
194
No. Material Name Finished Product Code Remarks
14
Display Board
'30294000009 1
15
Base Plate Assy
'011007000038 1
16
Crankshaft
'200023000001 2
17
Stepping Motor
'1521240215 2
18
Left Side Plate
'2690940007001 1
19
Main Board
'300002062363 1
20
Terminal Board
'42200006005601 1
21 Terminal Board '422000060015 1
22
Electric Box Assy
'100002073094 1
23
Support Of Motor Bearing
'01792408 1
24 Bearing Holder Sub-
assy
'26909400050 1
25
Propeller Housing(Lower)
'200230000001 3
26
Roller Wheel
'700004500433 1
27 Filter Sub-
Assy
'111001000001 2
28
Centifugal Fan
'103003000001 3
29 Rear Side Plate Sub-
Assy
'017051000005 1
30
Joint Slack
'73018731 1
31
Propeller Housing(Upper)
'200230000002 3
32
Brushless DC Motor
'150104060113 1
33
Axile Bush
'10542704 2
34
Ambient Temperature Sensor
'3900012123 1
35
Temperature Sensor
'3900019204 1
36
Remote Controller
'305001060060 1
