No. Material Name Finished Product Code Quantity
14 Guide Louver 20000450042601 2
15 Bearing Holder Sub-assy 26909400050 2
16 Support Of Motor Bearing 01792408 2
17 Display Board 30294000009 1
18 Crankshaft 200023000001 2
19 Stepping Motor 1521240215 2
20 Base Plate Assy 011007060032 1
21 Left Side Plate 2690940007001 1
22 Electric Box Assy 100002074224 1
23 Main Board 300002062363 1
24 Terminal Board 42200006005601 1
25 Terminal Board 422000060015 1
26 Centifugal Fan 103003000001 4
27 Propeller Housing(Upper) 200230000002 4
28 Rear Side Plate Sub-Assy 017051000006 1
29 Filter Sub-Assy 111001000001 3
30 Drainage Pipe Sub-assy 05235434 1
31 Swing Lever 10582009 4
32 Air Louver 20000700000101 20
33 Water Tray Assy 000069060048 1
34 Front Grill 2690940006601 4
35 Filter Sub-Assy 11729400004 1
