Greenlee 38456 - Page 7

Hydraulic Punch Driver
Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
7
Parts List—Punch Driver
Key Cat. No.
UPC No.
78-3310-
Description 7646 7306SB 7306 7310SB 7310 7625 7606SB 7610SB 7304 7506
A 746 17091 Ram (includes keys B, C, D) 1 1 1 1 1 1 1 1
746SS 30387
Ram (includes keys C, D
and 29452)
1
29451 29451 7/16" Stainless Steel Draw Stud 1
29452 29452 3/4" Stainless Steel Draw Stud 1
B 2113B 10109 3/4" Piston Shaft 1 1 1 1 1 1 1 1
C 54167 54167 1/4" Coupler Unit 1 1 1 1 1 2 2 2 1
D 54168 54168 Dust Plug 1 1 1 1 1 2 2 2 1
E 1557AA 03170 Screw Sleeve 1 1 1 1 1 1 1 1
F 20963 20963
3/8" Adapter Draw Stud
(3/4–16 x 3/8–24)
1 1 1 1 1 1 1 1
G 15908 15908
Spacer Group
(includes keys H, I, J)
1 1 1 1 1 1 1 1 1
H 1924AA 03248 Short Spacer 1 1 1 1 1 1 1 1 1
I 1925AA 03249 Medium Spacer 1 1 1 1 1 1 1 1 1
J 1926AA 06904 Long Spacer 1 1 1 1 1 1 1 1 1
K 34410 34410 Kwik-Stepper
®
Pilot Bit 1 1 1 1 1 1 1 1 1
L 767 13284 Hydraulic Hand Pump 1 1 1 1 1 1
M 38316 38316
1/4" x 3' High-Pressure Hose Unit
(includes keys N, O)
1 1 1 1 1 1
N 54169 54169 1/4" Coupler Unit 1 1 1 1 1 2 2 2 1
O 54170 54170 Dust Cap 1 1 1 1 1 2 2 2 1
06302 06302
1/4" x 3' High-Pressure Hose
with Swivel (without couplers)
1 1 1 1 1 1
P 1725 31353
Hydraulic Foot Pump
(includes keys C, D)
1 1 1
Q 37729 37729
1/4" x 10' High Pressure Hose Unit
(includes two each of keys N, O)
1 1 1
52515 52515
1/4" x 10' High Pressure Hose
Replacement (without couplers)
R 30206 30206 Plastic Carrying Case 1 1 1
18402 18402 Plastic Carrying Case 1 1
S 23955 23955 Metal Carrying Case 1 1 1
30236 30236 Plastic Carrying Case 1
31068 31068 Metal Carrying Case 1
