MAINTENANCE
VERTICAL STORAGE FUNCTION (See Figure 14)
• Remove the battery from the mower.
• Remove the grass catcher bag.
• Rotate the handle knobs to the unlocked position.
• Lower the handle assembly and rotate the handle knobs to the locked position.
• Lift the mower by the front end to the vertical position.
STORAGE SWITCH:
When the handle is rotated into the fully locked storage position, the mower is equipped with a
storage switch (1) that will disable the mower from running in the storage position. The storage
switch (1) does not replace the need to remove the safety key and battery to prevent accidental
start-up or unauthorized use.
WARNING
Always remove the battery from the mower before placing the unit in the vertical storage position.
27
Locked
position
Unlocked
position
Fig. 14
(1)
Storage switch
