Anaesthetic gas scavenging system AGSS
Greggersen Gasetechnik GmbH, Bodestraße 27-29, 21031 Hamburg, Germany, Fon +49 (0)40-73 93 57-0
04.12.13/GR/ AGFS-Forano.dts.eng.pdf
6
Technical data
Type: All metal design, plug-in ejector for generating a vacuum, one-hand
operation for plugging in and out, visual signal for operating control,
integrated valve for capacity adjustment.
ush mounting/hollow wall: stainless steel installation housing, stainless
steel front plate with visual signal.
Connections: Supply lines
pressure gas line: Cu-tube 8x1
exhaust line: Cu-tube 15x1
Outlet/ejector
pressure gas supply: coupling for 4 mm PA-hose
or 6 mm hose nozzle
ejector: coupling for 4 mm PA-hose
or 6 mm hose nozzle
anesthesia gas exhaust: 15 mm hose
visual signal: coupling for 4 mm PA-hose
Capacity: at least 50 l/min at propellant pressure of 500 kPa
Gasconsumption: power gas: ≈12 l/min at ow 50 l/min
Color: magenta-red designation, according to DIN EN ISO 9170-2
Installation: • ush-mounting or hollow wall mounting
• ceiling supply systems
• wall supply systems
dimensions see annex
Guidelines: DIN EN ISO 9170-2
DIN EN ISO 7396-2
Medical Devices Directive 93/42/EEC; Classication: IIa
Important information
• Comply with DIN EN ISO 7396-2 for the installation of AGSS systems!
• Comply with TRGS 525 for operating the anesthesia gas exhaust system!
• Use only original GREGGERSEN spare parts!
Service/Maintenance
External disinfection with a cloth is sucient for all chrome-plated brass parts. Clean plastic parts
with a common disinfectant solution and follow manufacturers instructions. Let outlets and plug
dry completely before using them again.
Prior to each use, make a visual check of the outlets (external damages). Outlets and plug should
be controlled at least once a year (capacity, function); in very frequently used areas accordingly
more frequently!
Failures and damages may only be remedied by authorized expert personnel. For repairs, use only
original GREGGERSEN spare parts!
