Anaesthetic gas scavenging system AGSS
Greggersen Gasetechnik GmbH, Bodestraße 27-29, 21031 Hamburg, Germany, Fon +49 (0)40-73 93 57-0
04.12.13/GR/ AGFS-Forano.dts.eng.pdf
7
Assembly notes
The installation housing for the hollow wall/ush mounting design must rst be mounted inside
the wall! Then the outlet is set in.
Hollow wall mounting: Fasten housing with 6 screws left and right; solder pipes to the pipeline
system
Flush mounting: Plaster housing into the wall; solder pipes to the pipeline system
Fasten outlet with 2 screws into casing
Connect outlet by means of connection lines to the pipe or ejector connections (ejector can be
plugged and xed with 1 screw!)
Push front plate onto the housing and fasten with 2 screws
Start-up
Adjust suction capacity with valve spindle (11 o’clock position) with hexagon ttings
(2,5 mm)
Press the actuator on the outlet
Check anesthesia gas exhaust system according to DIN EN ISO 7396-2
