Greiff TFEB 240 - Assembly Step 5: Lighting; TFEB Light Fitting Installation; MB;TFB Housing and Lights

MonteringsanvisningMB/TF/TFE/TFB/TFEB Motala2016‐09‐15
AssemblyinstructionMB/TF/TFE/TFB/TFEB
 GreiffIndustrimiljöAB
Dynamovägen17
SE‐59161Motala
 12 
Monteringsteg5
Assemblystep5

TFEB
Märkut,borrahålochmonteraarma tur påvalfriplaceringitaketpåboxen.
Measureanddrillholesforthelightfittingsatanydesirablelocation.










   Figure32 
MB/TFB
Byggihopresterandeväggarochtaksamtfrontprofiler.Skruvasedanditarmaturernaidelösa
armaturkåporna.Läggsedanpåglasskivaocharmaturmedkåpaöverhålenitaksektionerna.
Glasskivornakanmedfördelmonterasiefterhandinifrånboxenförattsäkerställaattdeintetar
skadaunderövrigmontering.
Mounttherest
ofthewalls,roofandfrontframeprofiles.Alsomountthelightfittingsintothe
housing.Thenplacetheglassandhousingwiththelightfittingontopoftheholesintheroof
sections.Theglassca n preferablybemountedfrominsidetheboothafterwardstoensurethatthey
don´ttakedamageduringresidualassembly.








Figure33   Figure34

