OPENING DOORS
GRIFFWERK GMBH | LINDENSTR.  |  BLAUSTEIN | PHONE +     | FAX +     | INFOGRIFFWERK.DE
DURING INSTALLATION
1. Drill support cams to 7 mm horizontally (not bigger)
For this purpose, we recommend the GRIFFWERK drilling template
2. Rebate gap max. 3.5 mm (door adjustment)
3. Tighten grub screws properly
by GRIFFWERK
7 7
38
90°
