9
Grillo G131
195 kg.
1997
7.5-12/3000
tipo
serie
massa c.a.
anno
KW/giri minuto
S.p.A.
CESENA - ITALY
Cod. 03293
IDENTIFICATION AND AFTER-SALES SERVICE
The vehicle’s serial number is punched on the nameplate on the left-hand
longitudinal member of the chassis and on the gearbox nameplate.
Always state the serial number when ordering spare parts.
AFTER-SALES SERVICE
This handbook provides instructions for use of the cultivator and for
correct basic servicing which the user can carry out himself.
For all procedures not described in this handbook, contact your local dealer.
SPARE PARTS
Always use original spare parts, as they are the only ones to offer complete safety and interchangeability.
Always state the serial number when ordering. For engine parts, refer to the specific handbook.
WARRANTY
The warranty conditions are as indicated on the law in force.
The engine warranty conditions are those of its manufacturer.
THE FOLLOWING SPARE PARTS SHOULD ALWAYS BE KEPT TO HAND:
– 1 gas wire
– 1 clutch wire
– 1 cable throttle
– 5 right tines with screws
– 5 left tines with screws.
ORDERING SPARE PARTS
Always state the machine serial number and the code number of the part to be replaced.
Contact your local dealer.
G131 TECHNICAL DATA
ENGINES:
LOMBARDINI 3 LD 510
RUGGERINI MD 150
Also available with electric starter.
MACHINE:
Clutch: dry, single plate, manual control.
Gearbox: with gears in oil bath; 5 forward speeds and 2 reverse.
Travel speeds in km.p.h. (mph) with engine at 3000 rpm are the following:
GEARS TIRES TIRES
5.00-12 6.5/80-15
1st
1,18 1,39
2nd
2,42 2,86
3rd
3,44 4,07
4th
7,06 8,36
5th
14,53 17,22
1st R
1,72 2,03
2nd R
3,53 4,18
Power Take Off: upper synchromesh P.T.O. (optional); lower P.T.O. at 1028 rpm clockwise, with engine
at 3000 rpm.
Reverse Speed Interference: a safety device which prevents the engagement of the reverse speed if the P.T.O.
is engaged.
Wheels: Tires 5.00-12; tires 5.00-15, 6.5/80-15 and 6.5/80-12 optional.
Differential gear: with locking device and control lever near the handle.
Handle: reversible and adjustable in several positions either in height or width.
