Page 12
Tools required (not supplied)
Cross Head Screwdriver (Philips) Spanner
Fittings
X 2
X 18X 14
X 4 X 2
M4X8 screw
Silver
M6 washer
M6X12 screw
M4X12 screw
NOTE: ALL HARDWARE IS DRAWN IN FULL SCALE TO HELP IDENTIFY EACH
PART
X 2
M4X10 screw
GSCL30R / GSCL30GR / GSCL30BL
Prepare frame for assembly
Lift hood, remove & unpackage all items except burners & burner assembly.
Proceed to step 1
To Next Page
