Grimac TWENTY - SECTION 6 - WIRING DIAGRAM

50
SECTION 6 - WIRING DIAGRAM
GROUND ( GND)
GROUND ( GND)
GROUND ( GND)
BLACK
GREY
BROWN
BLUE
YELLOW/GREEN
PHASE ( S)
PHASE ( R)
PHASE ( T)
NEUTRAL ( N)
BLACK
GREY
BROWN
BLUE
YELLOW/GREEN
PHASE ( S)
PHASE ( T)
PHASE ( R)
BLUE
BROWN
BLACK
GREY
YELLOW/GREEN
PHASE ( L)
NEUTRAL ( N)
400 VOLT
THREE-PHASE+NEUTRAL
230 VOLT
SINGLE-PHASE
220 VOLT
THREE-PHASE
PLUG
(according to the country,
only "1 group" type machine
is equipped with)
110/230 VOLT
SINGLE-PHASE
