The Grindhouse Shift is a portable vaporizer designed for use with dry herbs, wax, and thick oils. It features a compact design and offers precise temperature control for an optimized vaping experience.

Function Description:

The Grindhouse Shift is a "True Convection Vaporizer" that heats materials evenly to produce vapor. It is designed for adult use and is not a medical device. The device is intended for vaporizing legal dry herbs, wax, and thick oils, and should not be used with tobacco or concentrate materials. It includes safety features such as an automatic shut-off after 4 minutes of inactivity to prevent overheating and conserve battery life. The device utilizes an OLED digital screen to display important information such as battery status, current temperature, and auto shut-off countdown.

Important Technical Specifications:

Size: 50 x 27.3 x 81 mm
Battery Capacity: 1600mAh
Charging Voltage/Current: 5V/1A
Charging Time: Less than 2 hours (approximately 1.5 hours for a full charge)
Temperature Range: 320°F - 430°F
Safety Power Duration: 240 seconds (4 minutes auto shut-off)
Heat Time: 25 seconds

Usage Features:

Power On/Off: Rapidly press the Power button 5 times within 2 seconds.
Charging: Connect the Grindhouse Shift to the included USB charger and plug it into a USB port. A "Charging" graphic will appear on the OLED screen. The unit is fully charged when the battery icon is full. Do not let the unit hang during charging to avoid damaging the USB connection.
Initial Use: Before first use, heat the unit a few times empty to burn off any manufacturing impurities.
Loading Dry Herb:
1. Push the top lip of the mouthpiece away from the unit.
2. Load ground material loosely into the heating chamber. For best results, fill the chamber halfway or slightly more, but do not pack tightly to allow for even heat distribution.
3. Snap the mouthpiece back in place.
Loading Wax & Thick Oils:
1. Remove the mouthpiece.
2. Pull the silicone cap off the quartz cup.
3. Load wax or thick oil into the quartz cup.
4. Replace the silicone cap on the quartz cup.
5. Place the loaded quartz cup into the chamber.
6. Re-attach the mouthpiece.
Temperature Control: Adjust the desired temperature manually using the "+" and "-" buttons.
Fahrenheit/Celsius Toggle: Press and hold the power button and the "-" button simultaneously for 2 seconds to switch between Fahrenheit and Celsius.
Heating Indicator: When heating, the indicator light within the mouthpiece will glow RED. Once the desired temperature is reached, it will turn GREEN, indicating the session is ready.
Auto Shut-Off: The device automatically shuts off after 4 minutes. To reactivate the heating element, press the power button 5 times in rapid succession.
Low Battery Indicator: A "Low Battery Symbol" will be displayed on the OLED screen when the battery is low.

Maintenance Features:

Cleaning:
1. Push the top lip of the mouthpiece away from the unit.
2. Remove the spent material from the chamber using the stir tool.
3. Use the cleaning brush to remove and clean debris from the chamber.
Silicone Mouthpiece Screen Replacement:
1. Remove the mouthpiece.
2. Pull the old silicone screen off at the tab.
3. Replace with a new silicone screen ring.
4. Securely press the new silicone screen ring into place.
Storage: Always store the Grindhouse Shift in a dry, shaded place to protect the battery from the elements.

Safety Warnings and Warranty:

Do not expose to extreme temperatures or direct sunlight.
Do not drop or submerge in any liquid.
Do not modify the electronics.
Only use Grindhouse brand chargers and accessories.
Keep all parts, concentrates, herbs, and liquids away from children and pets.
Consult a physician before use if you have heart disease, other medical conditions, or are pregnant/breastfeeding.
The device comes with a 1-year limited warranty covering manufacturer defects or malfunctions under normal use. The warranty does not cover normal wear and tear, improper use, accidental damage (dropping, submerging in liquid), improper cleaning, neglect, or other non-defective damage. Improper use will void the warranty. For warranty servicing, contact WWW.GRINDHOUSEGRINDERS.COM.
