8 9
17
EN
E
Place the module on a firm surface, far from
flood-prone areas. It is recommended that the
module be mounted on a wall with the fixing
holes on the upper part.
Once the module has been mounted, connect
the power cable (17) to the module’s power
supply input (9) and the transformer to a
110~230VAC outlet.
With this connecon made your module is
powered and the LED indicator (13) should
start to blink. You also now have power availa-
ble on the Power output connector (1).
6
