ASSEMBLE THE BOTTOM PLATE HOLDER TO BACK END
STEP 3
INSERT THE BOTTOM PLATES
STEP 4
x1 x1
35mm Bolts
HF
Bottom Plate Holder
DC
x2
Bottom Plates
DF
