Ground Zero GZRF 4.0SQ - Specifications; Mounting and Installation

GROUND ZERO GZRF SQ coaxial loudspeakers
RADIOACTIVE SERIES
Technische Daten / Specifications
Montage / installation
Modell / model
GZRF 4.0SQ
GZRF 5.2SQ
GZRF 6.5SQ
GZRF 69SQ
Nominaler Durchmesser
Nominal diameter
10 cm
4“
13 cm
5.25“
16,5 cm
6.5“
15 x 23 cm
6“ x 9“
Lautsprecher Version
Loudspeaker type
2-Wege Koaxial
2-way coaxial
3-Wege Koaxial
3-way coaxial
Impedanz
Impedance
3 Ohm / ohms
Frequenzgang
Frequency response
70 Hz – 24 kHz 60 Hz – 24 kHz 50 Hz – 24 kHz 40 Hz – 25 kHz
Belastbarkeit (Watt RMS / max)
Power handling (Watts RMS / max)
70 / 110 80 / 120 100 / 140 130 / 200
Wirkungsgrad
Efficiency (SPL)
90 dB 90 dB 91 dB 92 dB
Einbaudurchmesser
Installation (mounting) diameter
93 mm
3.66”
117.5 mm
4.63”
142.5 mm
5.61”
214 x 152 mm
8.4” x 5.98”
Einbautiefe
Mounting depth
47 mm
1.85”
59 mm
2.32”
68 mm
2.68”
82 mm
3.23”
