GROUND ZERO GZTA 2255X-B
TITANIUM SERIES
Specifications
Model
GZTA 2255X-B
Amplifier type
2 channel class A/B high power amplifier
Output power
2 x 150 W RMS @ 4 Ohm ≤ 1% THD+N
2 x 250 W RMS
@ 2 Ohm ≤ 1% THD+N
2 x 300 W max
@ 2 Ohm ≤10% THD+N
1 x 500 W bridged @ 4 Ohm ≤
1% THD+N
1 x 600 W bridged @ 4 Ohm ≤10% THD+N
Damping factor
> 100
High pass crossover
HPF: 5 Hz – 500 Hz (12 dB/oct)
Low pass crossover (BP)
LPF: 40 Hz – 4000 Hz (12 dB/oct) (HPF active for band pass configuration)
Frequency response
5 Hz – 38 kHz (± 1 dB)
Bass Boost
0 to 12 dB (45 Hz)
Input sensitivity
0.5 V – 9 V (± 5%)
Fuse(s)
2x 30A
Dimensions
w x h x l (mm/inch)
230 x 53 x 395
9.04” x 2.09” x 15.55”
GZTA 2255X-B
yellow color side panels included
