BACKPACK SPRAYER
Introduction
To get the most out of your new backpack
sprayer, please read through these
instructions before use.
Please also save the instructions in case you
need to refer to them at a later date.
Technical data
Capacity: 16 litres
Working pressure: 0.20-0.45 MPa
With adjustable shoulder strap, 120 cm hose,
60 cm lance, plastic pump and built-in safety
valve with a maximum pressure of 1.0 MPa.
Main components
1. Nozzle
2. Lance
3. Pump handle
4. Lock button
5. Trigger button
6. Hose
7. Pump unit
8. Carrying handle
9. Filler cap
10. Tank
The backpack sprayer is also equipped with
adjustable shoulder straps (not shown).
Special safety instructions
Be careful if you use toxic or chemical
pesticides.
Be aware that even a slight breeze can carry
mist and fi ne drops of pesticide spray away
from the place you are using the backpack
sprayer.
Always equalise the pressure before
unscrewing the pump unit or putting the
backpack sprayer into storage. The backpack
sprayer must not be left unattended if the
tank is pressurised.
Wash the backpack sprayer thoroughly after
use.
Remember to wash your hands thoroughly
after you have fi nished using the backpack
sprayer.
1
2
3
4
6
5
7
8
9
bl
1
2
3
4
5
6
bl
7
8
9
