Grove Crane RT760 - Lifting Capacities - Power Pinned Fly Extended (Config 4); Power Pinned Fly Retracted Data; Power Pinned Fly Extended Data

RT760
12
THIS CHART IS ONLY A GUIDE AND SHOULD NOT BE USED TO OPERATE THE CRANE. The individual crane's load chart, operating instructions and other instructional plates must be read and understood prior to operating the crane.
35 - 110 ft.
(10.7 - 33.5 m)
13,900 lbs.
(6305 kg)
360°
50%
32 ft.
(9.8 m)
85% Domestic (Pounds)
(Degrees)
0°
OFFSET
15°
OFFSET
30°
OFFSET
POWER PINNED FLY RETRACTED
75
20,600
(26.7)
15,600
(33.2)
10,600
(37.9)
70
17,500
(36.2)
13,100
(42.2)
9,700
(46.7)
65
12,950
(45.3)
11,500
(50.9)
8,900
(55.1)
60
9,230
(54.1)
8,170
(59.1)
6,890
(63.1)
55
6,650
(62.5)
5,860
(66.9)
4,970
(70.5)
50
4,800
(70.4)
4,200
(74.1)
3,560
(77.3)
45
3,460
(77.7)
2,980
(80.7)
2,510
(83.5)
POWER PINNED FLY EXTENDED
75
12,500
(36.6)
9,700
(41.7)
8,100
(46.9)
70
11,000
(48.1)
8,900
(52.9)
7,600
(57.7)
65
7,890
(59.2)
7,520
(63.7)
7,000
(68.1)
60
5,320
(69.9)
5,200
(74.0)
4,680
(77.9)
55
3,520
(80.1)
3,510
(83.8)
3,020
(87.1)
50
2,220
(89.6)
2,190
(92.8)
1,810
(95.6)
45
1,240
(98.4)
1,140
(101.2)
A6-829-014094A
NOTE: ( ) Reference radii in feet.
BOOM
ANGLE
