Grove Crane RT760 - Lifting Capacities - Power Pinned Fly Retracted (Config 3); Power Pin. Fly Ext. & 85 ft. Data

RT760
8
THIS CHART IS ONLY A GUIDE AND SHOULD NOT BE USED TO OPERATE THE CRANE. The individual crane's load chart, operating instructions and other instructional plates must be read and understood prior to operating the crane.
Power Pin.
Fly Ext.
& 85 ft.
35 40 45 55 65 75 85 110
10
83,400
(65)
80,050
(68)
76,750
(71)
70,900
(75)
12
53,850
(61)
53,850
(65)
53,850
(68)
53,850
(73)
52,000
(76)
15
34,750
(55.5)
34,750
(60)
34,750
(64)
34,750
(69.5)
34,750
(73)
20
20,600
(44.5)
20,600
(51)
20,600
(56.5)
20,600
(63.5)
20,600
(68.5)
20,600
(72)
20,600
(74.5)
25
14,850
(31)
14,850
(41)
14,850
(48.5)
14,850
(57.5)
14,850
(63.5)
14,850
(68)
14,850
(71)
17,600
(76)
30
10,900
(28)
10,900
(39)
10,900
(51)
10,900
(58.5)
10,900
(63.5)
10,900
(67.5)
13,450
(74)
35
8,280
(26.5)
8,280
(44)
8,280
(53)
8,280
(59)
8,280
(63.5)
10,400
(71)
40
5,200
(35.5)
5,200
(47)
5,200
(54.5)
5,200
(60)
8,140
(68)
45
3,510
(24.5)
3,510
(40.5)
3,510
(49.5)
3,510
(55.5)
6,340
(65)
50
2,420
(32.5)
2,420
(44)
2,420
(51.5)
4,890
(62)
55
1,660
(22.5)
1,660
(38)
1,660
(46.5)
3,690
(59)
60
1,110
(31)
1,110
(41.5)
2,690
(56)
65
1,840
(52.5)
70
1,110
(49)
Minimum boom angle (deg.) for indicated length (no load) 40.5 48.5
Maximum boom length (ft.) at 0 deg. boom angle (no load) 65 75
Note: ( ) Boom angles are in degrees.
Boom
Angle
35 40 45 55 65
0°
11,150
(29.6)
8,650
(34.3)
5,620
(39.3)
2,570
(49.3)
1,190
(59.3)
Note: ( ) Reference radii in feet.
A6-829-012349A
35 - 110 ft.
(10.7 - 33.5 m)
13,900 lbs.
(6305 kg)
360°
75% Domestic (Pounds)
0%
Power Pinned Fly Retracted
(Feet)
