GrowSpan 2000 Series - End Frame Base Plate Layout (B)

4
GK2EW24120B_G Revision date: 12.06.19
End Frame Base Plate Layout (B)
0" @ PLATE EDGE
0" @ PLATE EDGE
1 1/2" 7 1/2"
3'-6 3/4"
4'- 1/4"
7'-8 3/4" 8'-2 1/4"
16'-6 3/4"
17'- 1/4"
20'-8 3/4" 21'-2 1/4" 24'-1 1/2" 24'-7 1/2"
4 1/2" 3'-9 1/2" 7'-11 1/2" 16'-9 1/2" 20'-11 1/2" 24'-4 1/2" 24'-9" @ PLATE EDGE
NOTE:
USE PLATE CENTERS FOR GROUND POST APPLICATION.
A
A
111817 DETAIL
(OPTIONAL)
3"
6"
5 1/2"
8"
7/8" TYP.
1 1/4"
PLATE CENTERS:
A
NCHOR HOLE CENTERS:
SECTION "A-A"
